Turn your 3D creations into PEN-AND-INK
The Process
-
Models are brought into Blender as .glb, .obj, or .fbx’s.
-
Sculpted or auto-generate models are remeshed in Blender using voxel remeshing, followed by quadriflow remeshing.
-
Silhouettes and contours are generated using Blender’s grease pencil, and exported to .svg’s.
Hatch work is generated in plotter fun from shadow and cavity passes. -
Generated .svg’s are brought into Adobe Illustrator for cleanup.
-
Processed .svg’s are imported into Inkscape. Vector art is plotted on vellum or hot-press watercolor paper using an Axidraw S3/V3 pen plotter and technical pens.
The Payoff
Turn-table animation of a skull and cervical vertebrae. Frames were created with a pen plotter, and line art was generated by converting 3D models into vector art.
CD8 (red and pink) complexed to HLA and the T-Cell Receptor. Based on PDB entries 1AKJ and 7PHR
Click the image to explore the source material.
Proteosome complex, based on PDB entry 1FNT.
Click the image to explore the source material.
Partial viral capsid of cucumber mosaic virus, based on PDB entry 1CGM.
Click the image to explore the source material.
Viral capsid of a rhinovirus particle, based on PDB entry 1FPN.
Click the image to explore the source material.
Calcium pump, based on PDB entry 1SU4.
